description of the product
SYSTEM
- non-rebated system
EXTRA CHARGES
- door frame lower by 55 mm or 100 mm
- door frame higher by 50 mm or 100 mm
- door frame higher by 150 mm or 200 mm
- width „100”
- width „110”
- reinforcement for the arm/guide rail door closer***
- architraves interconnected at the 90° angle
- electric action door strike BIRA HARTE XS narrow with slip (reverse) XS12R-C 12V DC (including SPEC-525 catch plate and a cut for the electric strike)**
- electric action door strike BIRA HARTE XS narrow with slip (averse) XS12U-C 12V AC/DC (including SPEC-525 catch plate and a cut for the electric strike)**
- electric action door strike BIRA HARTE XS narrow with slip (averse with switch) XS12UW-C 12V AC/DC (including SPEC-525 catch plate and a cut for the electric strike)**
- crown
The installation door width must be enlarged by 15 mm for the DUO non-rebated system door leaves equipped with the HOBES lock.
Door frames with ranges wider than the maximum ones provided in the table above are available (upon consultation with the Sales Department).
*environment-friendly acrylic paints, RAL and NCS colours (except metallic ones) – available at an extra charge according to the colour groups
** for leaves equipped with the ECO Schulte GBS 12 - extra charge, the installation hole width increased by 25 mm
***NOTE! The recommended dimension of the installation hole height increased by 16 mm.
DIMENSIONS
|
single leaf door
|
|||||
|
WIDTH
|
|||||
|
typ
|
So
|
Sd
|
Ss
|
Sop
|
|
|
"60"
|
690
|
652
|
625
|
794
|
|
|
"70"
|
790
|
752
|
725
|
894
|
|
|
"80"
|
890
|
852
|
825
|
994
|
|
|
"90"
|
990
|
952
|
925
|
1094
|
|
|
"90 plus"
|
1015
|
977
|
950
|
1119
|
|
|
"100"
|
1090
|
1052
|
1025
|
1194
|
|
|
HEIGHT
|
|||||
|
|
Ho
|
Hd
|
Hs
|
Hop
|
|
|
|
2055
|
2043
|
2020
|
2133
|
|
|
double leaf door
|
|||||
|
WIDTH
|
|||||
|
typ
|
So
|
Sd
|
Sop
|
||
|
"60"+"60"
|
1304
|
1266
|
1408
|
||
|
"60"+"70"
|
1404
|
1366
|
1508
|
||
|
"60"+"80", "70"+"70"
|
1504
|
1466
|
1608
|
||
|
"60"+"90", "70"+"80"
|
1604
|
1566
|
1708
|
||
|
"70"+"90", "80"+"80"
|
1704
|
1666
|
1808
|
||
|
"80"+"90"
|
1804
|
1766
|
1908
|
||
|
"90"+"90"
|
1904
|
1866
|
2008
|
||
|
HEIGHT
|
|||||
|
Ho
|
Hd
|
Hs
|
Hop
|
||
|
2055
|
2043
|
2020
|
2133
|
||
Ss - door leaf width
Sd – door frame external width
So - installation hole width
Sop – architrave external width
Hs - door leaf height
Hd – door frame external height
Ho - installation hole height
Hop – architrave external height
It is possible to manufacture frames with larger ranges than the maximum specified in the table above (after consultation with the Sales Department).
Select a model
PAINTED
001 white (RAL 9003)
ECO TOP
120 white
121 oak
132 walnut
141 Salinas oak
158 honey oak
VENEERED
312 limba
334 European oak
323 rustic oak
340 ebony
351 marrone
390 natural walnut
404 dark walnut
405 bright walnut
421 cappuccino
422 mocca
424 teak
HIGH TOP
148 coffee ash
UNI MAT PLUS
640 graphite
641 titano
642 white
SILKSTONE
276 Polish oak
293 Royal anthracite
295 Royal merbau
297 Royal nougat
LAMISTONE CPL
240 whitewashed elm V
241 sand elm V
242 grey elm V
244 black
250 terra oak
258 white
260 white oak
263 premium walnut
289 grey
531 anthracite
LAMINATED CPL 0,2mm
820 white
222 grey
225 terra oak
821 anthracite
844 black
863 orzech premium
System
NON-REBATED SYSTEM
Surface
HIGH TOP
PAINTED
ECO TOP
LAMISTONE CPL
SILKSTONE
LAMINATED CPL
VENEERED
UNI MAT PLUS
GROSS PRICE FROM
1027,05 PLN
