SYSTEM
- rebated system
SPECIFICATION
- The installation hole must be enlarged for door frames equipped with an electric strike: by 5 mm for FD12, by 10 mm for FD14
- Powder-coated door frame. Standard colours: white (RAL 9016), white (RAL 9003), grey (RAL 7047), brown (RAL 8014), beige (RAL 1001), graphite (RAL 7024), black (RAL 9005). Other RAL colours are available at an extra charge - upon consultation with the Sales Department (except the metallic and pearl ones)
EXTRA CHARGES:
- door frame lower by 50 mm or 100 m
- door frame higher by 50 mm
- door frame higher by 100 mm
- door frame higher by 150 mm
- door frame higher by 200 mm
- reinforcement for the surface mounted door closer
- compatible with the electric door strike
- electric averse action door strike JiS typ 1710-12 AC (including a catch plate)
- electric averse action door strike BIRA HARTE XS narrow XS12U 12V AC/DC (including a catch plate)
- electric averse action door strike with switch BIRA HARTE XS narrow XS12UW 12V AC/DC (including a catch plate)
- electric reverse action door strike BIRA HARTE XS narrow XS12R 12V DC (including a catch plate)
- hinge M for the metal door frame (width “60”-”80”)
- replacement hinge with the T type hinge
DIMENSIONS
|
single leaf door FD14
|
|||||
|
WIDTH
|
|||||
|
typ
|
So
|
Sd
|
Sc
|
||
|
"60"
|
673
|
633
|
697
|
||
|
"70"
|
773
|
733
|
797
|
||
|
"80"
|
873
|
833
|
897
|
||
|
"90"
|
973
|
933
|
997
|
||
| "90" plus |
983
|
943
|
1007
|
||
| "100" | 1073 | 1033 | 1097 | ||
| "110" | 1173 | 1133 | 1197 | ||
|
HEIGHT
|
|||||
|
|
Ho
|
Hd
|
Hc
|
||
|
|
2046
|
2036
|
2068
|
||
|
double leaf door FD14
|
|||||
|
WIDTH
|
|||||
|
typ
|
So
|
Sd
|
Sc
|
||
|
"120"
|
1307
|
1267
|
1331
|
||
|
"130"
|
1407
|
1367
|
1431
|
||
|
"140"
|
1507
|
1467
|
1531
|
||
|
"150"
|
1607
|
1567
|
1631
|
||
|
"160"
|
1707
|
1667
|
1731
|
||
|
"170"
|
1807
|
1767
|
1831
|
||
|
"180"
|
1907
|
1867
|
1931
|
||
|
"190"
|
2007
|
1967
|
2031
|
||
|
"200"
|
2107
|
2067
|
2131
|
||
|
HEIGHT
|
|||||
|
Ho
|
Hd
|
Hc
|
|||
|
2046
|
2036
|
2068
|
|||
|
single leaf door FD12
|
|||||
|
WIDTH
|
|||||
|
typ
|
So
|
Sd
|
Sc
|
||
|
"60"
|
681
|
671
|
697
|
||
|
"70"
|
781
|
771
|
797
|
||
|
"80"
|
881
|
871
|
897
|
||
|
"90"
|
981
|
971
|
997
|
||
| "90" plus |
991
|
981
|
1007
|
||
| "100" | 1081 | 1071 | 1097 | ||
| "110" | 1181 | 1171 | 1197 | ||
|
HEIGHT
|
|||||
|
|
Ho
|
Hd
|
Hc
|
||
|
|
2060
|
2055
|
2068
|
||
|
double leaf door FD12
|
|||||
|
WIDTH
|
|||||
|
typ
|
So
|
Sd
|
Sc
|
||
|
"120"
|
1315
|
1305
|
1331
|
||
|
"130"
|
1415
|
1405
|
1431
|
||
|
"140"
|
1515
|
1505
|
1531
|
||
|
"150"
|
1615
|
1605
|
1631
|
||
|
"160"
|
1715
|
1705
|
1731
|
||
|
"170"
|
1815
|
1805
|
1831
|
||
|
"180"
|
1915
|
1905
|
1931
|
||
|
"190"
|
2015
|
2005
|
2031
|
||
|
"200"
|
2115
|
2105
|
2131
|
||
|
HEIGHT
|
|||||
|
Ho
|
Hd
|
Hc
|
|||
|
2060
|
2055
|
2068
|
|||
Sd – door frame external width
So - installation hole width
Sc – total door frame width
Hd – door frame external height
Ho - installation hole height
Hc - total door frame height
Select a model
metal fixed pol-skone
COLOURS - METAL
RAL 9016
RAL 9005
RAL 9003
RAL 8014
RAL 7047
RAL 7024
RAL 1001
