description of the product
SYSTEM
- non-rebated system
EXTRA CHARGES
- door frame lower by 55 mm or 100 mm
- door frame higher by 50 mm or 100 mm
- reinforcement for surface mounted door closer**
- electric action door strike BIRA HARTE XS narrow with slip (reverse) XS12R-C 12V DC (including SPEC-525 catch plate and a cut for the electric strike)***
- electric action door strike BIRA HARTE XS narrow with slip (averse) XS12U-C 12V AC/DC (including SPEC-525 catch plate and a cut for the electric strike)***
- electric action door strike BIRA HARTE XS narrow with slip (averse with switch) XS12UW-C 12V AC/DC (including SPEC-525 catch plate and a cut for the electric strike)***
Door frames with ranges wider than the maximum ones provided in the table above are available (upon consultation with the Sales Department).
*environment-friendly acrylic paints, RAL and NCS colours (except metallic ones) – available at an extra charge according to the colour groups
**NOTE! The recommended dimension of the installation hole height increased by 16 mm.
*** for leaves equipped with the ECO Schulte GBS 12 - extra charge, the installation hole width increased by 15 mm
DIMENSIONS
|
single leaf door
|
|||||||
|
WIDTH
|
|||||||
|
typ
|
So
|
Sd
|
Ss
|
Sop
|
Sopl
|
Sopf | |
|
"60"
|
690
|
652
|
625
|
793
|
793
|
795 | |
|
"70"
|
790
|
752
|
725
|
893
|
893
|
895 | |
|
"80"
|
890
|
852
|
825
|
993
|
993
|
995 | |
|
"90"
|
990
|
952
|
925
|
1093
|
1093
|
1095 | |
|
"90 plus"
|
1015
|
977
|
950
|
1117
|
1118
|
1120 | |
|
HEIGHT
|
|||||||
|
|
|
Ho
|
Hd
|
Hop
|
|
||
|
|
|
2062
|
2050
|
2333
|
|
||
Ss - door leaf width
Sd – door frame external width
So - installation hole width
Sop – architrave external width
Hd – door frame external height
Ho - installation hole height
Hop – panel external height
Select a model
PAINTED
001 white (RAL 9003)
VENEERED
312 limba
334 European oak
323 rustic oak
340 ebony
351 marrone
404 dark walnut
405 bright walnut
421 cappuccino
422 mocca
424 teak
SILKSTONE
276 Polish oak
293 Royal anthracite
295 Royal merbau
297 Royal nougat
LAMISTONE CPL
240 whitewashed elm V
241 sand elm V
242 grey elm V
244 black
250 terra oak
258 white
260 white oak
263 premium walnut
289 grey
531 anthracite
System
NON-REBATED SYSTEM
Surface
PAINTED
LAMISTONE CPL
SILKSTONE
VENEERED
GROSS PRICE FROM
1233,69 PLN
