INTERIOR DOOR ETIUDA

ETIUDA doors, thanks to the combination of aluminum slats and striking glazing, will add a fashionable charm to your arrangement. Solid and glazed models available.

• solid construction – wooden rail and stile set
• large LAMISTONE CPL and SILKSTONE surface finish
• white matt and graphite tempered glass,
  thickness: 6 mm
• aluminium decorative strips in the colour of silver or black
• K and C type adjustable and DUO type concealed hinges

STANDARD EQUIPMENT:

• white/brown matt tempered glass, thickness: 6 mm
• black-coloured glass pane is not available
• glazing width in the A01 version – 54 mm; A02 – 205 mm,
  A03 – 276 mm*
• single-point mortise lock, spacing: 72 mm (rebated system) or magnetic
  mortise lock (non-rebated system), key-operated (spacing: 90 mm),
  for a cylinder (spacing: 85 mm) or a bathroom lock (spacing: 90 mm)
• hinges: type K – for the DIN system door frame, type C – for the
  wooden door frame, type M – for the metal door frame or the
  concealed DUO satin nickel (”60”-”80” – 2 pcs, ”90” – 3 pcs)
• in case of door leaf with door closer and DIN system or metal frame
  to be used T type hings ( „60”-„80” – 3 pcs, „90”-„110” – 4 pcs) -
  replacement of standard hinges with hinge type T for an extra charge



ADDITIONAL EQUIPMENT (AVAILABLE AT AN EXTRA CHARGE):

• size “100”
• size “110” (applicable to the version B0, B1)
• perforated chipboard in-fill (versions B0, A01, A02, A03)
• solid chipboard in-fill (versions B0, A01, A02, A03) (third hinge
  recommended)
• third hinge in the door leaf or adjustable pivot hinge:
  type K, type C, type M for a width of ”60”-”80”
  concealed DUO type for a width of ”60”-”80”
• the DUO lock colour replaced with black or golden gloss colour
• rail and stile set (allowing the user to shorten the door leaf by
  max. 50 mm on a do-it-yourself basis) (applicable to versions B0)
• rail and stile set (allowing the user to shorten the door leaf
  by max. 90 mm on a do-it-yourself basis) (applicable to versions B0)
• reinforcement for door closer
  (not applicable to the version A01, A02, A03)
• bottom rail and stile set protection against excessive moisture impact
  (not applicable to leaves with ventilation trim)
  (not applicable to versions A01, A02, A03)
• door lower by 50 mm or 100 mm (rebated system)
  (not applicable to versions A01, A02, A03)
• door lower by 55 mm or 100 mm (non-rebated system)
  (not applicable to versions A01, A02, A03)
• door higher by 50 mm or 100 mm (not applicable to versions
  A01, A02, A03) (third hinge in the door leaf is required)
• door higher by 150 mm or 200 mm (not applicable to versions
  A01, A02, A03) (third hinge in the door leaf is required)
• version A01, A02, A03 door lower by 50 mm (rebated system)
• version A01, A02, A03 door lower by 55 mm (non-rebated system)
• version A01, A02, A03 door higher by 100 mm (third hinge in the door
  leaf is required)
• version A01, A02, A03 door higher by 200 mm (third hinge in the door
  leaf is required)
• ventilation trim (applicable to versions B0, B1)
• ventilation trim A01 with the "60” - "100" widths
• ventilation trim A02, A03 with the "70” - "100" widths
• tempered 6 mm glass in the colour of graphite or transparent
• change of colour of decorative strips to black:
  version B1
  version A01-A03
• sliding system
